Technical data
| Axle load: | 8 - 12 t |
| Suspension Axle Centers: | 1232 / 1384 / 1360 / 1538 mm |
| Spring Pack: | 8 – 13 leaf; 3 leaf - parabolic |
| Spring Width: | 75x10 - 16 mm, 25 mm - parabolic |
| Suspension Hangers: | Casting; Equalizer fitted with tapered rubber or poly bushes |
| Right Height: | 200 - 475 mm; Under / Overslung |
| Axle Clamp Group: | ø 127 / 146 / 150 mm |
Product information
The YORK YTE 75 mechanical suspension is a product specifically developed for general transportation requirements in delivery services. It fits perfectly for highway and modern road use.
The YORK YTE 75 offers the following:
- Weight preference on 3 leaf springs.
- Mechanical suspensions suitable for on road and off-road conditions.
- Mechanical Suspension –fitted with swivel equalizers for better braking performance
