SAF Hercules

The SAF Hercules is the 24 t standard landing gear for the most common vehicle applications.

Technical data





Lift capacity:  24,000 kg
Static load capacity: 50,000 kg
Lift in low gear: 1 mm per turn
Lift in high gear: 12 mm per turn
Standard foot: compensator foot
Mounting height / lift: 655 / 350 mm
  705 / 400 mm
  750 / 410 mm
  800 / 460 mm
  850 / 510 mm



Product information

The SAF Hercules has a particularly optimized mounting height / lift ratio for the low mounting heights, thus this series can be used in low Mega semi-trailers  up to high semi-trailer tippers.

 The main features are:

  • Continuous 10 hole 3D back plate

  • Various foot options

  • Wide range of accessories

  • Powder coating with high quality pretreatment

  • Web-based spare part identification by QR code

  • 3 years maintenance free
