HOLLAND SK-V36

The heavy-duty slider HOLLAND SK-V36 is designed for an imposed load of 36 t.

Technical data





Total Slider Travel: 800 mm
Imposed Load: 36,000 kg
Overall heights: 57 mm (basic height)
D-Value: 260 kN
ECE Test no.: E11 55R-01 7609



Product information

The HOLLAND SK-V36 heavy-duty slider has been developed for an optimal utilization of permissible axle load and vehicle length.

The main features are:

  • Slider for heavy-duty fifth wheels with 150, 190 mm over all height
  • Safe and easy single hand operation
  • Available for different frame widths 760 - 800 mm
  • Connection hole pattern according to DIN 74081 / 74084 and ISO 3842

Approved for forced steering

Literature

Document Thumbnail
Product catalogue
PDF / 15.96 MB
